Wiring Flexible Tube

Merchandise details

●This product is using an environment-friendly material which does not contain a halogen substance.
Wiring Flexible Tube
　　　* Patent pending


       ⇒ Example of the use
Features
・Even without tools from the plane slit portion can be easily inserted and pulled out of the wire.
　   (also available without a slit type.)
・Wire is housed in the tube, and improves the appearance of the wiring.
・Step-cross-door part I can use to protect the diverse routing of over wiring and the like.
・Four direction / six direction it is possible to bend freely.
・The five colors standard lineup is possible color-coded identification of circuit by such a plurality of lines available.
・Standard / flame retardant / high flame retardant the lineup.
Color
・Natural ・White ・Orange ・Black ・Yellow
・Blue ・Green ・Silver ・High brightness Silver
Material
・Polyethylene (LDEP) /Fire-resistant polypropylene (PP)
Operating temperature
・LDEP : -20℃～50℃
・PP     : -20℃～60℃






Type List(KFT)
Product Code configuration

       　KFT4　          　PE　            1309           　BK　           -           　 A　
       　①Shape　　　　②Material　　　　③Size　　　　 ④Color　　 　　　　　　⑤Slit existence

①Shape ②Material ③Size ④Color ⑤Slit existence


Square

ＫＦＴ４


LDPE　PE

PP(flame retardant)        PP1

PP(High flame retardant) PP2

13mm× 9mm 1309

30mm×20mm 1309

40mm×30mm 4030
  		Natural  NA
White    WT
Orange  OR
Black     BK
Yellow   YE
Blue      BL
Green    GR
Silver     SL
Silver    SL2
        (High brightness)

* Natural only LDPE
* High brightness Silver
order products


Yes   -   A

No    -   N




Hexagon

ＫＦＴ６


LDPE　PE

PP(flame retardant)        PP1

PP(High flame retardant) PP2



10mm　10



Designation Format
Square-type

Designation Format KFT4

 Material:ＬＤＰＥ 　　　　　　　　　　　　　　　　　　（unit：mm）
Size ａ ｂ ｃ ｄ ｅ ｆ ｇ m/Case
1309 9.0 13.0 6.3 10.5 0.3 0.4 (2.7) 50
3020 20.0 30.0 15.0 25.0 0.6 0.6 (5.4) 15
4030 30.0 40.0 25.0 35.0 0.5 0.7 (5.4) 15
Material:ＰＰ
Size ａ ｂ ｃ ｄ ｅ ｆ ｇ m/Case
1309 9.2 13.2 6.3 10.5 0.3 0.35 (2.7) 50
3020 20.0 30.0 15.0 25.0 0.6 0.6 (5.4) 15
4030 30.0 40.0 25.0 35.0 0.5 0.7 (5.4) 15


Hexagon-type

Designation Format KFT6

  　　　　　　　　　　　　　　　　　　　(unit:mm)
Material ａ ｂ ｃ ｄ m/Case
ＬＤＰＥ 10.3 7.5 0.35 (2.7) 50
ＰＰ 10.5 7.7 0.35 (2.7) 50

　　　　　　               * The value of (　) is a reference only
