Slide Lock tube Clear type

Merchandise details

Slide Lock tube Clear type
Features
・Possible to confirm inside wires because sheet side is transparent
・High sealed in mating parts and difficulty into dust from outside structure
・Easily to populate the tubes using special slider
・Cleared 1200V withstand voltage test on sheet part.
Type List (KSL-C)
Part No. Nominal Size Length Materials/Characteristics
KSL-15C 15φ 50m *Sheet section:
Fire resistant vinyl chloride
*Interlock section:
Fire-resistant semi-rigid vinyl chloride
KSL-20C 20φ
KSL-25C 25φ
KSL-30C 30φ
KSL-35C 35φ
KSL-40C 40φ
KSL-50C 50φ
KSL-70C 70φ 25m
KSL-100C 100φ
Color
Clear
Packaging
・The external case has a slot from which you can pull the tube out to use.
・Not using any metallic parts, the bobbin and the external case can be readily disposed of.
Interlock
・The tube can be interlocked easily using the exclusive slider (optional).
