Features
・Resistance to chemicals
・Resistance to climate
・Resistance to adherence
・Resistance to flame
・Electrical insulating properties
Material
Fluorine resin
・PFA
Application
Protection of electronic device line
Transfer tube of solvent and drug solution
Transfer tube of corrosive fluid
Transfer tube of causticity fluid
Operating temperature
-60～250℃
Type List (KPFA)
| Part No. |
I.D.(mm) |
O.D.(mm) |
thickness(mm) |
Length(m) |
| KPFA-3x2 |
3.0 |
2.0 |
0.5 |
100 |
| KPFA-4x2 |
4.0 |
2.0 |
1.0 |
100 |
| KPFA-4x3 |
4.0 |
3.0 |
0.5 |
100 |
| KPFA-6x4 |
6.0 |
4.0 |
1.0 |
100 |
| KPFA-8x6 |
8.0 |
6.0 |
1.0 |
100 |
| KPFA-10x8 |
10.0 |
8.0 |
1.0 |
100 |
| KPFA-12x10 |
12.0 |
10.0 |
1.0 |
50 |
| KPFA-19x16 |
19.0 |
16.0 |
1.5 |
50 |
| KPFA-25x22 |
25.0 |
22.0 |
1.5 |
50 |
Physicality Materials
| Item |
Testing method |
Unit |
Standard value |
| Ratio |
ASTM D792 |
- |
2.14～2.16 |
| Fusing point |
DSC |
℃ |
300～310 |
| Intake rate |
ASTM D570 |
％ |
<0.01 |
| Tension strength |
JIS K6891 |
MPa |
30.4～34.3 |
| Stretch |
JIS K6891 |
％ |
300～400 |
| Flame retardant |
UL-94 |
- |
V-0 |
*This information is not a guaranteed value but Standard it
