Fluorine Spiral Tube

Merchandise details

Fluorine Spiral Tube
Features
・Strong resiliency and not easy to break
・Possible to band and protect wires
・Easy to change wires
Material

Fluorine resin ・PFA

Application
Protection of band cables
Type List (KPFAS)
Part No. I.D.(mm) O.D.(mm) thickness(mm) Length(m)
KPFAS-3X2 3.0 2.0 0.5 20
KPFAS-4x3 4.0 3.0 0.5 20
KPFAS-6x4 6.0 4.0 1.0 20
KPFAS-8x6 8.0 6.0 1.0 20
KPFAS-10x8 10.0 8.0 1.0 20
KPFAS-12x10 12.0 10.0 1.0 5
KPFAS-19x16 19.0 16.0 1.5 5
KPFAS-25x22 25.0 22.0 1.5 5
Physicality Materials
Item Testing method Unit Standard value
Ratio ASTM D792 - 2.14～2.16
Fusing point DSC ℃ 300～310
Intake rate ASTM D570 ％ <0.01
Tension strength JIS K6891 MPa 30.4～34.3
Stretch JIS K6891 ％ 300～400
Flame retardant UL-94 - V-0
*This information is not a guaranteed value but Standard it
